Pickling lines eliminate oxide and scale from the band surface on hot rolled coils. The process is based on passing the band through hydrochloric baths which dissolve the surface oxides like ferric oxide Fe2O3, ferrous oxide FeO, and ferric-ferrous oxide Fe3O4. The pickling process efficiency largely depends on the material chemical composition, bath temperature, removal of the same, acid concentration and tank length.
Carbon Steel Pickling line
Pickling lines eliminate oxide and scale from the band surface on hot rolled coils. The process is based on passing the band through hydrochloric baths which dissolve the surface oxides like ferric oxide Fe2O3, ferrous oxide FeO, and ferric-ferrous oxide Fe3O4. The pickling process efficiency largely depends on the material chemical composition, bath temperature, removal of the same, acid concentration and tank length.
1. Key Technology
Push-pull Pickling line and Shadow trough turbulence acid pickling technology.
2. Main Technical data
| 1 | Main input Material | hot rolling carbonstructure steel, high quality carbon structure steel and low alloy steel coil, silicon steel; |
| 2 | Production capacity | 200,000- 600,000tons annually ( Max annual capacity is 1,000,000 tons at present) |
| 3 | Thickness of steel strip | 1.5-5.5mm |
| 4 | Width of steel strip | 350-1,450mm (whenless than 600mm, semi-continuous method will be adopted); |
| 5 | Processing speed | 30-180m/min(depend on the needs of output) |
| 6 | Coil weight | Max. 25tons |
| 7 | Technology | push-pull shallow trough turbulence acid pickling |
| 8 | Energy | water, electricity, steam |
3.Its main type
350-1450mm width steel strip
4.Process Flow
Major equipments in turns are as follows:
Crane hoisting coils to skids →coil laoding car→ decoiler (pressure roller, anti-curve roller) → decoiling scraper → Deflector roll → verticalguide roller → pinch roller straightener → crop shearer →corner shearer(with scrap bucket) → vertical guide roller → pre-washing trough → four-grade hydrochloric acid pickling trough → four-gradewashing trough (Including pre-washing section) → edge blowing device→ hot air dryer → II# pinch roller → looper (Both ends are equipped with looper swing stand) → vertical guide roller → pinch centering machine → circle shearer (With waste edge recoiler) → 3-roller tension roller → crosscut shearer → vertical guide roller → steering pinch roller → recoiler → coil unloading trolley → coil receiving stand→Crane hoisting coils to storage house
5.Sales Performance list
| 序号 | 年份 | 业主名称 | 机组规格 |
| No | Year | Clients | Production Line Specification |
| 1 | 2018 | 越南Vietnam | 1450mm酸洗线拆改装 1450mm pickling line demolition modification
|
| 2 | 2011 | BS钢铁制品有限公司 Bd Iron and Steel Products Co., Ltd. | 1450mm酸洗生产线（酸再生） 1450 mm Pickling line(including acid regeneration) |
6.High end customized Manufacture for Steel strip pickling line
If the advertised pickling line is not what you need, please tell me more about your requirement, we can design and manufacture as you required.
